The Dexing porphyry copper field in Jiangxi, China, is defined by three porphyry copper deposits which are, from southeast to northwest, Fujiawu, Tongchang and Zhushahong respectively, and by the Guanmaoshan gold deposit which lies between Fujiawu and Tongchang. Technically, the field lies on the southeastern edge of the Jiangnan Anteclise, and is controlled by the NE-trending, deep-seated, Gandongbei fracture zone. The emplacement of the ore-bearing Fujiawu, Tongchang and Zhushahong granodiorite porphyry intrusions, dated at 184-172 Ma (Zhu et ah, 1983; Zhu et al9 1990), was also controlled by NW-trending structures. Mineralisation and alteration continued from 172 Ma to 100 Ma, and are characterised by symmetric zoning centred on the contacts between granodiorite porphyries and the enclosing country rocks of the Mesoproterozoic Shuangqiaoshan Group jrfryllites.

Magmatic-related porphyry copper and high-sulphidation epithermal copper-gold ore deposits are spatially and temporally clustered in arc segments that underwent crustal shortening during magmatic differentiation. In the ductile lower crust or uppermost mantle, geodynamically induced horizontal compression inhibits propagation of subvertical dykes and can keep buoyant magmas trapped in sheet-like, subhorizontal chambers. Layered ultramafic-mafic cumulates crystallise within these chambers until the regional stress regime relaxes or until further magmatic differentiation generates the buoyancy needed to overpower the stress field and permit magma ascent. In the hot lower crust or uppermost mantle, magma chambers tend to last long enough to experience multiple episodes of replenishment by primitive magma, partial mixing of arriving mafic and resident evolved melts, and fractional crystallisation of those hybrids. Over a succession of replenishment and partial-crystallisation cycles, the melt's concentration of incompatible chemical components (H20, CI, S03, etc.) follows a "sawtooth ramp-up" time series. Multi-cycle magma chambers thereby become exceptionally fertile for magmatic-hydrothermal Cu metallogeny.

Newly-recognised porphyry-style mineralisation within the Ertsberg intrusion displays significant differences from porphyry mineralisation at the Grasberg porphyry Cu-Au deposit. Stockwork mineralisation in the Ertsberg occurs near the giant East Ertsberg Skarn System, close to the northern margin of the intrusion. Stockwork mineralisation in the diorite is spatially associated with 5-15 m wide, E-striking, dykes of porphyritic hornblende monzonite that cut equigranular Ertsberg diorite. The porphyry dykes strike parallel to major district structures and occur where those structures project into the Ertsberg intrusion. Hornblende abundance greater than biotite, the much greater content of sphene, a paucity of broken phenocrysts, and the aplitic groundmass distinguish the porphyry dykes in the Ertsberg Stockwork Zone from the finer-grained groundmass Kali dykes of the Grasberg deposit.

 The Grasberg Igneous Complex (GIC) is host to one of the largest copper and gold porphyry-type ore deposits discovered on Earth. Much of the rock volume in the GIC has been pervasively altered by the infiltration of hot, magmatic fluids. In parts of the deposit, alteration destroyed all igneous phases. Petrography reveals that two zones characterise almost the entire complex at the level of the open pit mine. The 1 km-wide core of the deposit is dominated by biotite + magnetite with an inner ~500 m-wide sub-zone containing andalusite. The exterior annular zone, -500 m across, is dominated by sericite + anhydrite + pyrite with small amounts of kaolinite. Pockets of rock contain epidote with chlorite in the distal portions of the GIC.

The Grasberg Igneous Complex, which formed at ~3 Ma, is host to one of the largest copper and gold porphyry-type ore deposits discovered on Earth. This study focuses on the magmatic characteristics of the three main phases of intrusion at the level of the open pit mine: the Dalam, subdivided into the Dalam Andesite, Dalam Volcanic and Dalam Fragmental, the Main Grasberg Intrusion (MGI), and the Kali (Early and Late). A sample suite consisting of 225 polished slabs and thin sections shows all units contain plagioclase and biotite as the dominant phenocryst phases. The Dalam Andesite, MGI and Late Kali contain(ed) hornblende as well. The Late Kali and the MGI also contained minor amounts of clinopyroxene. Apatite is ubiquitous as a trace phase. Magmatic magnetite is identifiable in the Late Kali. The magmatic groundmass in the Kali, MGI, and Dalam Andesite was potassium feldspar, albitic plagioclase, quartz and biotite. A similar groundmass assemblage probably existed in the other Dalam phase rocks, but hydrothermal alteration caused complete replacement. The phenocryst assemblages record no profound changes in magma chemistry over time, but the parent chamber was probably recharged at least twice, and possibly many times.

Ordovician volcanic, volcaniclastic and intrusive rocks of calc-alkaline affinity in the Eastern Subprovince of the Lachlan Orogen were formed in the intraoceanic Macquarie Volcanic Arc. The Macquarie Arc was developed in response to west-dipping subduction along part of the boundary between eastern Gondwana and the proto-Pacific Plate and was situated on the Gondwana Plate, some 1000 km east of Precambrian continental crust. The intervening area was occupied by a back arc basin that developed on oceanic crust as the proto-PacificPlate rolled back eastwards after the Middle Cambrian Delamerian Orogeny. Subsequent extension, strike-slip translation and thin-skinned tectonics have structurally dissected the single arc into four north to NNE trending structural belts of Ordovician calc-alkaline rocks that are separated largely by younger rift basins and in part by coeval craton-derived turbidites.

Copper-molybdenum and copper-gold porphyry deposits in the Quesnel terrane occur in association with either calc-alkalic or alkalic intrusive suites respectively, emplaced within a succession of island arc volcanic rocks that are of Late Triassic to Middle Jurassic or Late Cretaceous to Eocene age. The Highland Valley porphyry district, in southern British Columbia, consists of five major copper-molybdenum deposits, Valley, Lornex, Bethlehem, Highmont and J A, located within a fifteen square kilometre area in the centre of the Guichon Creek batholith. The batholith is a Late Triassic calc-alkalic intrusion that REE data suggest was derived from either subducted oceanic crust or depleted mantle. The crystallisation age of the batholith, based on U-Pb zircon analyses, is 210 Ma. Mineralisation occurred in late magmatic and early post magmatic time. Oxide analyses suggest a single source magma but younger phases were locally injected into older due to tectonic forces. The earliest deposits occurred after separation of a fluid phase that is marked by a sharp discontinuity in the evolution path of the alkali oxides.

The Bingham deposit is centred on a small 40 Ma stock of older, generally equigranular, monzonite that is cut by quartz monzonite porphyry, latite, and quartz latite porphyry dykes. The surrounding country rocks are quartzite and minor but important limestone. A body of fractured rock formed over the top of the monzonite as it cooled leaving a weakly fractured core below a dome of strong fracturing. Early fluids entered this fractured mass at about the time of the intrusion of the first porphyry resulting in an undetermined amount of alteration and mineralisation. This fracturing is a major control on the location of the ore shell and the concentric zoning pattern of alteration and mineralisation. Five porphyry intrusives have been described and each is followed by a cycle of veining, alteration and mineralisation. The porphyries all trend north-easterly across the northern half of the deposit, forming the porphyry trend. At least three overlapping centres of fracturing, alteration and mineralisation seem to be present within the stock, one centred in the fracture dome and two or more in the porphyry trend.

More than fifty significant porphyry copper deposits are distributed over a 2000 km interval within the U.S. and Mexico, following a trend subparallel to the southwestern margin of North America. These include giant supergene enriched deposits such as those at Morenci in Arizona (4.7 Gt @ 0.52% Cu) and Cananea (7.1 Gt @ 0.42% Cu) in Sonora, Mexico.

The porphyry copper deposits of southwestern North America were developed in a continental margin cratonic setting, above a subduction zone that was active largely from the Early Mesozoic to the Late-Tertiary. While significant ore deposits of Jurassic to Mid-Tertiary age are known, the majority were emplaced between 72 and 55 Ma, during the peak of magmatic activity along the Laramide Arc. Laramide magmatism and crustal shortening ceased by around 50 Ma, in the mid Eocene, to be followed by a 15 m.y. period of magmatic quiescence, erosion and localised continental sedimentation, the Eocene Epeirogeny. This was succeeded from around 35 Ma by the Mid-Tertiary Orogeny, which persisted through the Oligocene to the Early Miocene and resulted in renewed, widespread volcanism, and by crustal extension. Extension was characterised by the development of listric, detachment and strike-slip faults, associated listric tilting of up to 60° or more, and the uplift and exposure of metamorphic core complexes. During the Mid- to Late-Miocene, between 18 and 10 Ma, the nature of tectonism in the region changed through a period of transition, from an extensional to a block faulted 'basin and range' regime which persists locally to the present. The typical basins are grabens or half grabens, with structural relief between the base of sediment filled basins and the crests of the adjacent ranges of from 2 to 4 km, and sometimes more than 6 km.

Antamina is the largest known copper-zinc skarn (>3000 Mt @ 1.1% Cu and 1.3% Zinc) in the world. It is located in the Northern Andes in Peru, 270 km north of Lima. The deposit formed at approximately 10 Ma by the emplacement of quartz monzonite intrusions into Mid to Late Cretaceous limestones of the Celendin and Jumasha Formations. Mineralisation is hosted as a series of zoned green and brown garnet endoskarns and exoskarns in the form of chalcopyrite, bornite and sphalerite. Elements present within the deposit of significant quantities to affect concentrate value are Cu, Zn, Mo, Ag, Bi and Pb. Antamina produces four concentrates, namely, copper (chalcopyrite and bornite), zinc (sphalerite), molybdenum and lead-silver-bismuth.
